brake disc grinding machine
The brake disc end surface precision grinder is specially designed and made in the field of civil automobile repair brake disc. It has compact structure and covers little space. The brake disc finish by the grinder is with high precision. The accuracy and appearance after trimming can be comparable to the brake disc state when the new car leaves the factory. The grinder operation is simple and intuitive, and the precision is easy to control.
Technical parameters
Overall packaging dimensions Gross weight | L*W*H: 1270 * 920* 1220 mm 225 kg |
Installation and usage size Net weight | L*W*H: 1050 * 720* 990 mm 178 kg |
Wiring mode Voltage | 4 - line 380V + 220V |
Power of motor | 1.5 kW / 120 W |
Maximum installation size of disc | 420 mm in diameter |
Maximum grinding size of disc | Diameter: 420mm/Thickness: 42mm Width: 100 mm |
Grinding brake disc working face axial offset | ≤0.005 mm |
Surface roughness | ≤0.8μm |
Grinding and machining speed (piece*) | 5 - 8 min/disc ( Diameter 350 - 400 mm) |
Grinding wheel speed | 2800 rpm |
Workpiece speed | 120 / 200 / 500 rpm |
